X series

X series LED screen has the characteristics of seamless perfect display, long lifespan, fast refresh frame frequency, high refresh rate, good uniformity, wide viewing angle, high gray level and natural color reproduction. It is widely used for command & dispatch, security monitoring, video conference, demonstrations and various indoor conference rooms.

  • NANOSCALE RESPONSE

    NANOSCALE RESPONSE

  • HDR Technology

    HDR Technology

  • Front Maintenance

    Front Maintenance

  • Extra wide viewing Angle

    Extra wide viewing Angle

  • HD Seamless Splicing

    HD Seamless Splicing

Product Parameters

Model X1.27 X1.588 X1.906 X2.5
LED Encapsulation 1010 black light 1212 black light 1515 black light 2121 black light
Pixel Pitch (mm) 1.27 1.588 1.906 2.54
Resolution 619414 pixels/m² 396424 pixels/m² 275295 pixels/m² 154853 pixels/m²
Lamp Bead/IC NATIONSTAR gold wire/High refresh rate
Panel Resolution 480*270 384*216 320*180 240*135
Panel Dimension (mm) 610*343*33
Panel Weight 5.3kg/pcs
Operating Voltage DC +4.2V
Maintenance Method Front maintenance
Brightness 200~600CD/m²
Contrast ≥10000:1
MTBF ≥10000H ≥20000H ≥20000H ≥20000H
Operating Voltage (AC) 220V±10%/50Hz or 110V±10%/60Hz
Average Power Consumption ≤200W/m²
Maximum Power Consumption ≤550W/m²
Protection Level IP5X
Temperature Storage:-35℃~+85℃ Operating:-10℃~+40℃
